WWP-4050EP

Express sealing packing machine

This edge sealing express packing machine is designed for high-efficiency automatic sleeve film sealing, cutting, and packaging, widely used in mass production lines. It features automatic film feeding, punching, sealing, cutting, and waste coiling, with easy adjustment for different product sizes without changing molds. Equipped with Omron digital temperature control and PID function, it ensures precise sealing temperature and reliable protection. The machine supports mixed-size packaging for promotional applications, includes safety protection covers, and uses a synchronized film correction system for stable operation, enabling fully automated, unmanned production line integration.

| Parameter | Specification |
| --- | --- |
| Brand | WIN-WIN PACK |
| Model | WWP-4050EP |
| Power Supply | 220V, 50/60Hz |
| Power | ≤2 kW |
| Packing Size | 100 mm |
| Cutter Size | L550 × W450 mm |
| Product Dimensions | L + H ≤ 500 mm, W + H ≤ 430 mm, H ≤ 100 mm |
| Machine Dimensions | 1830 × 850 × 1550 mm (The actual size shall prevail) |
| Packing Speed | 10–20 pcs/min |
| Air Pressure | 5.5 kg/cm² |

1. When the package size changes, adjustment is simple. No need to replace the mold or bag maker.

2. Products with different sizes can also be combined for packaging to achieve promotional effects.

3. Equipped with the original **Omron digital temperature controller** with built-in PID function. The sealing knife temperature is highly sensitive and accurate, and can be freely adjusted. It prevents product damage caused by inaccurate temperature control. The sealing knife also features an automatic protection function to effectively prevent incorrect cutting of the package.

4. The sealing and cutting section is equipped with a protective cover, greatly improving operator safety.

5. The complete machine system can be integrated into a production line to achieve truly unmanned operation.

6. Specially designed upper and lower film synchronization mechanism effectively corrects film deviation.
